Parent Layer: Flood Zones

Name: Stream Profile Baseline

Display Field: SEGMT_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: A line feature class of Federal Emergency Management Agency (FEMA) stream profile baseline arcs within Arlington County. A Profile Baseline shows the path of riverine flood flows on the Flood Insurance Rate Map (FIRM) and is an accurate representation of the distance between cross sections, structures, nodes or grids in the hydraulic model.Contact: Department of Environmental ServicesData Accessibility: Publicly AvailableUpdate Frequency: As NeededLast Revision Date: 11/14/2023Creation Date: 11/14/2023Feature Dataset Name: FEMALayer Name: FEMA_Stream_Profile_Baseline_arc

Copyright Text: Arlington County, Virginia; Department of Environmental Services; FEMA

Default Visibility: true

MaxRecordCount: 20000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.1861625832295552E7
YMin: 6971144.576563731
XMax: 1.1902670139314383E7
YMax: 7026316.254605979
Spatial Reference: 102746  (2283)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSDashDot
Color: [230, 76, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [255, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 4800.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID_1 ( type: esriFieldTypeOID, alias: OBJECTID_1 )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• DFIRM_ID ( type: esriFieldTypeString, alias: DFIRM_ID, length: 6 )
• VERSION_ID ( type: esriFieldTypeString, alias: VERSION_ID, length: 11 )
• BASELN_ID ( type: esriFieldTypeString, alias: BASELN_ID, length: 25 )
• WTR_NM ( type: esriFieldTypeString, alias: WTR_NM, length: 100 )
• SEGMT_NAME ( type: esriFieldTypeString, alias: SEGMT_NAME, length: 254 )
• WATER_TYP ( type: esriFieldTypeString, alias: WATER_TYP, length: 38 )
• SHOWN_FIRM ( type: esriFieldTypeString, alias: SHOWN_FIRM, length: 1 )
• R_ST_DESC ( type: esriFieldTypeString, alias: R_ST_DESC, length: 254 )
• R_END_DESC ( type: esriFieldTypeString, alias: R_END_DESC, length: 254 )
• V_DATM_OFF ( type: esriFieldTypeString, alias: V_DATM_OFF, length: 6 )
• DATUM_UNIT ( type: esriFieldTypeString, alias: DATUM_UNIT, length: 16 )
• FLD_PROB1 ( type: esriFieldTypeString, alias: FLD_PROB1, length: 254 )
• FLD_PROB2 ( type: esriFieldTypeString, alias: FLD_PROB2, length: 254 )
• FLD_PROB3 ( type: esriFieldTypeString, alias: FLD_PROB3, length: 254 )
• SPEC_CONS1 ( type: esriFieldTypeString, alias: SPEC_CONS1, length: 254 )
• SPEC_CONS2 ( type: esriFieldTypeString, alias: SPEC_CONS2, length: 254 )
• START_ID ( type: esriFieldTypeString, alias: START_ID, length: 25 )
• SOURCE_CIT ( type: esriFieldTypeString, alias: SOURCE_CIT, length: 11 )
• STUDY_TYP ( type: esriFieldTypeString, alias: STUDY_TYP, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
